Hard chrome plating power supply product uses:
Suitable for special electroplating surface treatment processes such as hard chromium plating.
1.Hard chrome plating power supply based on ordinary high-frequency rectified electroplating power supply.The output voltage is 6-18V.It has the functions of ordinary electroplating power supply.It is an ideal product for special electroplating surface treatment such as hard chromium plating.
2.It has multiple functions such as multi-step ladder power supply,multi-step soft start time setting,automatic reset,etc.,which can meet different process requirements.
3.Power Supply voltage stabilization and current limiting or current stabilization and voltage limiting function,control and display accuracy ≤1%.
4.The equipment has multiple protection functions such as output overcurrent,over temperature and input phase loss.The product is stable and reliable and the internal structure is reasonable.All electronic components are sealed,which reduces the impact of the external environments on the internal components of the equipment.
5.The control system can choose digital control,analog control or RS485 communication control,and can also be equipped with a 4-20mA,0-10V standard control signal interface.
|
hard chrome power supply parameters |
|
|
Input Voltage |
three phase AC 380±15% 50HZ |
|
Output Voltage |
0-12V、0-15V、0-18V、0-20V（can be customize） |
|
output Current |
0-2000A、0-3000A、0-4000A、0-5000A、0-6000A、 0-7000A、0-8000A、0-1000A、0-12000A、0-15000A、 0-20000A、0-30000A（can be customize） |
|
Adjustable Method |
Analog stepless adjustment/Intelligent digitization |
|
Adjustable Range |
Current:0-Maximum，Voltage:0-Maximum |
|
Output Display |
digital voltmeter、ammeter、intelligent human-machine touch screen |
|
Output Frequency |
30KHZ DC Square wave |
|
Output Time |
can be set 10 working time control+10 slow time control |
|
Output section waveform |
customers can be set it according to their process requirements |
|
Save File |
15 pieces（used for customers to store preset processes for easy recall next time） |
|
Phase Convert Switch |
mechanical communication（oil, water combined cooling system, need to be equipped with some functions when ordering instructions) |
|
Output Interface |
standard RS485、4-20MA、0-10V can be chosen |
|
Operating Environment |
-15~-40℃ |
|
Control Accuracy |
≤1% |
|
Insulating Strength |
≥5MΩ |
|
Insulating Grade |
Class B |
|
IP Degree |
IP20 |
|
Cooling Method |
air cooling/water cooling |
|
Working Mode |
products can be continuously full-load running |
|
Protection Mode |
self-protective function under the abnormal situations such as lack phase,overheating, over-current,short circuit, undervoltage,overvoltage and so on |
|
Regular Hard Chrome Type Selection |
|||||||
|
NO. |
Output Current(A) |
Output Voltage(V) |
Power |
Input Current(A) |
Input Voltage(V) |
Weight(KG) |
Length(L)*Width(W)*Height(H) (mm） |
|
YG1015 |
1000 |
15 |
15 |
25 |
380 |
45 |
550*450*320 |
|
YG1515 |
1500 |
15 |
22.5 |
37.5 |
380 |
70 |
580*510*680 |
|
YG2015 |
2000 |
15 |
30 |
50 |
380 |
80 |
520*580*930 |
|
YG3015 |
3000 |
15 |
45 |
75 |
380 |
80 |
400*520*930 |
|
YG4015 |
4000 |
15 |
60 |
100 |
380 |
100 |
500*620*1150 |
|
YG5015 |
5000 |
15 |
75 |
125 |
380 |
120 |
500*620*1150 |
|
YG6015 |
6000 |
15 |
90 |
150 |
380 |
130 |
500*620*1150 |
|
YG8015 |
8000 |
15 |
120 |
200 |
380 |
180 |
670*500*1450 |
|
YG10015 |
10000 |
15 |
150 |
250 |
380 |
250 |
1350*800*1350 |
|
YG12015 |
12000 |
15 |
180 |
300 |
380 |
300 |
1350*800*1350 |
|
YG15015 |
15000 |
15 |
225 |
375 |
380 |
300 |
1350*800*1500 |
|
YG20015 |
20000 |
15 |
300 |
500 |
380 |
350 |
1350*800*1980 |
|
YG25015 |
25000 |
15 |
375 |
625 |
380 |
550 |
1350*800*1980 |
|
YG30015 |
30000 |
15 |
450 |
750 |
380 |
600 |
1350*800*1980 |
|
there are many models，non-regularly can't be list.If U need electronic brochures and customized models,pls contact kimmy sales：+86 13760727815(WTS) |
|||||||
